Trento Entry Max Series 39″ Double Chamber Pizza Oven with 27.6″ Chamber – 11.2

Trento Entry Max Series 39″ Double Chamber Pizza Oven with 27.6″ Chamber – 11.2 kW, 230 V, 3 Ph



Item: 40636

Model: PE-IT-0038-D



FEATURES:
• Stainless steel front, two mechanical thermostats per chamber, heat resistant, light, main switch for each chamber, stainless steel door with glass and handle (Each chamber is independent)
• Up to 2 single-chamber oven can be placed on top of each other without the need for an exhauster connection
• Insulation is evaporated fiberglass
• Left-sided handles
• Upon request the machines can be produced in a “full refractory stone” version and for single-phase operation.

* Special Order are available for the following upon request: stands, casters, hoods, vents and suction motor



Technical

Maximum Temperature: 842° F (450° C)
Power: 11200 W
Electrical: 230V / 60Hz / 3Ph
Chamber Dimensions (WDH): 27.6” x 27.6” x 5.9” (x2) (700 x 700 x 150 mm) (x2)
Full Refractory Stone Dimensions (WDH): 26.4” x 27” X 5.31” (670 x 685 x 135 mm)
Net Weight: 328.5 lb. (149 kg.)
Net Dimensions (WDH): 39” x 36” x 26.7” (990 x 920 x 680 mm)
Gross Weight: 363 lb. (165 kg.)
Gross Dimensions (WDH): 40.2” x 39” x 32.3” (1020 x 990 x 820 mm)



Optional Parts & Accessories

Item 41422 – Stainless Steel Stand
Over-all Dimensions (WDH): 38.4″ x 32″ x 33.4″ (Height with wheels) / 31.7″ – 34.2″ (Min. – Max. Height with Adjustable Feet)
Net Weight: 66 lb. (30 kg.)

Item 41607 – Stainless Steel Hood
Over-all Dimensions (WDH): 39″ x 34.7″ x 5.9″
Net Weight: 22 lb. (10 kg.)

Item 40645 – Wheels for Pizza Oven Stands
